19Making Phone Grip-Toks with a UV Printer and Laser
We are explaining products you can make with a UV Printer.
Today, we will explain how to make phone grip-toks using a UV Printer and Laser.
Today, we will explain how to make phone grip-toks using a UV Printer and Laser.
I. Materials and Precautions — Making Phone Grip-Toks with a UV Printer and Laser
To make phone grip-toks from acrylic, you need an Ai file, UV Printer, Laser Cutting equipment, and grip-tok bases.
The production process is truly simple. Grip-tok bases are also known to be quite affordable when ordered in bulk.
1. Ai File Preparation
- The Ai file must contain 4 layers: Crop Mark Layer, Cut Line Layer, Color Image Layer, and White Spot Layer.
- For UV printing, 3 layers are used: Crop Mark Layer, Color Image Layer, and White Spot Layer.
- For Laser Cutting, 2 layers are used: Crop Mark Layer and Cut Line Layer.
- If you are curious about why 4 layers are needed, please refer to the link below.
- How Laser Cutters Use Cameras for Alignment
- For the Laser Crop Mark Cutting workflow after UV Printer printing, please refer to the link below.
- Explaining How to Perform Laser Camera Cutting
2. UV Printer, Acrylic, and Ink Adhesion
- Grip-toks are typically made from transparent acrylic.
- 3mm-thick acrylic is the most commonly used, and I also UV-printed on 3mm acrylic.
- Printing is done on the back side with Color and White.
- One of the most important factors is ink adhesion.
- Since the acrylic is attached to the grip-tok base with double-sided tape, if adhesion is weak, the ink may peel off. You must verify that the acrylic you use provides good ink adhesion.
- In actual production, companies apply manual primer to the acrylic before UV printing, use hard-coated acrylic to secure UV ink adhesion, or print with the machine’s built-in inkjet primer before Color and White printing.
3. Laser Cutting Equipment
- A laser cutter with camera cutting capability is the most convenient to use.
- After UV printing, the acrylic was cut using the camera cutting feature.
II. Production Process — Making Phone Grip-Toks with a UV Printer and Laser
1. UV Printing
- When making phone grip-toks, rather than using Color, White, Color as 3 layers, back-side printing is done with Color + White as 2 layers.
- Since ink adhesion is critical when attaching the acrylic to the grip-tok base with double-sided tape, pre-treated (coated) acrylic with secured ink adhesion was used.
- Since pre-treated acrylic was used, printing was done without manual primer or inkjet primer.
2. Laser Cutting
- The acrylic was cut as shown below.
-
Making Phone Grip-Toks with a UV Printer and Laser - This is a photo after cutting was completed.
-
Making Phone Grip-Toks with a UV Printer and Laser
3. Attaching Acrylic to the Grip-Tok
- The acrylic is attached to the grip-tok base using double-sided tape.
-
Making Phone Grip-Toks with a UV Printer and Laser
4. Attaching the Finished Grip-Tok to a Phone
- The grip-tok base has a protective film on the circular area.
- Simply peel off the protective film to reveal the double-sided tape, and attach it directly to the phone.
-
Making Phone Grip-Toks with a UV Printer and Laser
5. Phone Grip-Tok Production Video
- Everything explained above can also be viewed in the video below.
- ARTJET Phone Grip-Tok Production Video (youtube.com)
